Baitwell, Fwd Aquarium Style

Extensive Bow Casting Platform & Storage

Spacious Console Seating

Porta Pottie, Optional

Removable Windshield for Storage

Billet Gauge Switch Panel

Flip-Up Jump Seats

Rod Holder / Drink Holder Combos, Optional

Scarab Offshore Package, Optional

Ski Tow Pylon, Optional


8' 6"

Fuel Capacity

56 gal

Max Load

2350 lbs


Approx. Boat & Engine Weight 2650-3100 lbs 1202-1406 kg
Beam 8' 6" 2.54 m
Bridge Clearance w/T-Top 7' 4" 2.2 m
Deadrise 19° 19°
Approx. Draft Down 33" 84 cm
Approx. Draft Up 17" 43 cm
Fuel Capacity 56 gal 212 L
L.O.A 20' 4" 6.2 m
Max HP 200 HP 149 kW
Maximum Capacity 2350 lbs 1066 kg
Persons Capacity 8 8
Total height on Trailer 8' 8" 2.6 m
Total height on Trailer w/Top 10' 1" 3.1 m
Bridge Clearance 5' 8" 1.7 m
Persons Capacity CE 8 8
Print Specifications


Hull and Deck

  • Anchor locker w/ lid, latch & tie off
  • Bow & stern eyes, stainless steel
  • Bow floor storage
  • Cleats, fixed, stainless steel
  • Exterior color scheme, all white
  • Fiberglass liner, skid-resistant, self-draining
  • Fiberglass stringer system
  • Foam Flotation
  • Horn
  • Ladder, stern, telescoping & folding
  • Meets applicable uscg & canadian regs; nmma certified using abyc stds.
  • Navigation lights, LED
  • Rod holders, deck-mount
  • Rub rail w/ stainless steel insert
  • Thru-hull fittings, stainless steel
  • Winning edge owner protection plan


  • Assist handles, stainless steel
  • Baitwell/live well
  • Beverage holder(s)
  • Courtesy light(s)
  • Deck lids, easy-clean underside w/ flush-mount hinges
  • Diamond pattern non-skid
  • Helm seating, leaning post w/folding backrest
  • Leaning post
  • Rod storage, gunnel
  • Seating, aft folding bench(es)
  • Seating, forward console
  • Self bailing cockpit
  • Storage, bow


  • 12 volt receptacle
  • Cell phone holder
  • Steering wheel, stainless steel
  • USB charge port

Engine / Systems / Drive

  • Battery tray(s), dual w/ switch
  • Bilge pump, automatic


  • Changing room
  • Head floor, fiberglass liner
  • Windscreen, console


  • Wellcraft custom trailer, tandem axle w/brakes Galv/Gatorhyde

Power Options

  • Mercury® 115 ELPT 4S

Current Promotion

  • Fall Into Savings (Valid Sept. 6, 2019 to Nov. 30, 2019)

Option Packages

Bow Seating Package

  • Seat cushions, bow

Mat Package

  • Helm footrest, Marine Mat, diamond pattern
  • All marine mat backrests
  • Bow pads

Stainless Steel Upgrade

  • Cleats, pull-up, stainless steel
  • Grab handles, stainless steel
  • Additional aft rod/beverage holders (2)
  • Beverage holders, stainless steel

Offshore Package, White

  • Offshore graphic, white
  • Wellcraft logo & model designators, black
  • Mat package, Kryptek

Offshore Package, Black

  • Offshore graphic, black
  • Wellcraft logo & model designators, black
  • Mat package, Kryptek


Wellcraft offers you a selection of the best engines from leading manufacturers. Reliable performance that gets you where you want to go.

  • Yamaha® F115 XB
  • Yamaha® F150 XB
  • Yamaha® F200XB

  • Mercury® 115 ELPT 4S
  • Mercury® 150 XL 4S
  • Mercury® 200 FS DTS
  • Mercury® 200 FS DTS Warm White

Contact Your Dealership

Choose your location to find a dealer near you

Choose Location

* U.S. only, starting price on base model, excluding options and any applicable dealer charges, freight, prep, sales tax, title and registration fees.

* Wellcraft specifications, photography, video, features, and options are for reference purposes only. Models are shown with non-Wellcraft options and accessories. Options vary by model while some are shown with optional equipment. While Wellcraft makes every effort to ensure information contained herein is correct, content should not be regarded as infallible as unending product refinement and design changes may result in revisions to current models. Wellcraft reserves the right to change product specifications, models, features, imagery, video, and colors at any time without notification or incurring obligations. Representations herein do not constitute a warranty of any of the products shown. All limited warranties are outlined in the Wellcraft limited warranty that accompanies each boat. Please see your authorized Wellcraft dealer for additional information, option availability, and specific warranty details prior to purchase.
