Cleats, Pull-up

Fiberglass Stringer

Powdercoat Hardware

Cooler, Carry On

Diamond Pattern Anti-skid

Fishbox w/ Overboard Drain

Console Changing Room

Porta Pottie

Tackle Storage Curtains

Built-in Bait/Live Well

Beam

8' 6"

Fuel Capacity

158 gal

Max Load

3500 lbs

Specifications


L.O.A 24' 4" 7.4 m
Beam 8' 6" 2.54 m
Fuel Capacity 158 gal 598 L
Approx. Draft Up 16" 41 cm
Approx. Draft Down 34" 86 cm
Maximum Capacity 3500 lbs 3500 lbs
Persons Capacity 10 10
Approx. Boat & Engine Weight 4400-4900 lbs 1996-2223 kg
Max HP 400 HP 298 kW
Deadrise 20° 20°
Bridge Clearance w/T-Top 8' 6" 2.54 m
Total height on Trailer 9' 6" 2.9 m
Total height on Trailer w/Top 11' 4" 3.5 m
Bridge Clearance 6' 7" 2 m
Print Specifications

Features

Hull and Deck

  • Anchor locker/storage
  • Bow and Stern Eyes, stainless steel
  • Bow rails, stainless steel
  • Bow storage
  • Cleats, pull-up, stainless steel
  • Fiberglass floor liner
  • Fiberglass stringer system
  • Foam Flotation
  • Gel scheme, all white
  • Gel scheme, under hardtop color, all white
  • Grab handles, stainless steel
  • Horn, stainless steel
  • Ladder, boarding
  • Meets applicable USCG & Canadian Regs; NMMA Certified using ABYC Stds.
  • Navigation Lights
  • Powdercoat, white
  • Rod holders, aft transom mounted
  • Rod holders, gunnel mount
  • Rub Rail, w/stainless steel insert
  • Thru hull fittings, stainless steel
  • Transom lighting, LED
  • Winning edge protection plan

Cockpit

  • 5 gallon bucket(s) in holder
  • Assist handles, stainless steel
  • Baitwell/live well
  • Baitwell/live well, 17 gallon w/ bluecoat, light & timer
  • Baitwell/live well, 23 gallon w/ bluecoat
  • Beverage holder(s)
  • Bolsters, cockpit
  • Cooler, bow
  • Cooler, under leaning post (removable)
  • Courtesy lights
  • Deck lids w/stainless steel, latches gas assist
  • Diamond pattern non-skid
  • Leaning post, upgrade w/backrest, rod holders
  • Rod storage, gunnel
  • Seating, aft folding bench
  • Seating, forward console
  • Self bailing cockpit
  • Tackle storage w/boxes
  • Transom door

Helm

  • 12 volt receptacle
  • Compass
  • Steering wheel w/knob, stainless steel
  • USB charge port

Engine/Systems

  • Battery on/off switch
  • Battery tray(s)
  • Bilge pump, automatic
  • Hydraulic steering (std on 150 hp and up)
  • Raw water wash down
  • Trim tabs w/LED indicators

Console

  • Changing room
  • Head floor, fiberglass liner
  • Head, porta pottie (NA Canada)
  • Rod holders
  • Tackle storages curtains
  • Windscreen, console

Power Options

  • Mercury® 250 XXL

Hull Color

  • Wellcraft White

Under Hardtop Color

  • Wellcraft White

Option Packages

Bow Seating Package


  • Seating, bow cushion
  • Port, Starboard & Forward backrest cushions

Premium Sound Package


  • Stereo System
  • JL Audio Amplifier
  • JL Audio Speakers
  • JL Audio Subwoofer

Premium Sound Package w/ Deluxe T-top


  • Stereo System
  • JL Audio Amplifier
  • JL Audio Speakers
  • JL Audio Subwoofer

Offshore Package, Black


  • Wellcraft logo & model designators, black
  • Offshore graphic, black
  • Mat package, Kryptek

Offshore Package, White


  • Wellcraft logo & model designators, black
  • Offshore graphic, white
  • Mat package, Kryptek

Performance


Wellcraft offers you a selection of the best engines from leading manufacturers. Reliable performance that gets you where you want to go.


  • Mercury® 250 XXL
  • Mercury® 300 XXL
  • Mercury® 300 XXL Warm White
  • Twin Mercury® 150 XL 4S
  • Twin Mercury® 200 4S DTS
  • Mercury® 350 XXL
  • Mercury® 350 XXL Warm White
  • Mercury® 250 XXL Warm White
  • Twin Mercury® 200 4S DTS Warm White

  • Yamaha® F250 UCA
  • Yamaha® F300 UCA
  • Twin Yamaha® F150 XB
  • Twin Yamaha® F200 XCA
  • Twin Yamaha® F200 XB
  • Yamaha® F300 XCA2 White
