Specifications

Approx. Boat & Engine Weight 2650-3100 lbs 1202-1406 kg
Beam 8' 6" 2.54 m
Bridge Clearance w/T-Top 7' 4" 2.2 m
Deadrise 19° 19°
Approx. Draft Down 33" 84 cm
Approx. Draft Up 17" 43 cm
Fuel Capacity 56 gal 212 L
L.O.A 20' 4" 6.2 m
Max HP 200 HP 149 kW
Maximum Capacity 2350 lbs 2350 lbs
Persons Capacity 8 8
Total height on Trailer 8' 8" 2.6 m
Total height on Trailer w/Top 10' 1" 3.1 m
Bridge Clearance 5' 8" 1.7 m
Persons Capacity CE 8 8

Packages

Bow Seating Package

  • Seat cushions, bow

Mat Package

  • Helm footrest, Marine Mat, diamond pattern
  • All marine mat backrests
  • Bow pads

Stainless Steel Upgrade

  • Cleats, pull-up, stainless steel
  • Grab handles, stainless steel
  • Additional aft rod/beverage holders (2)
  • Beverage holders, stainless steel

Offshore Package, White

  • Offshore graphic, white
  • Wellcraft logo & model designators, black
  • Mat package, Kryptek

Offshore Package, Black

  • Offshore graphic, black
  • Wellcraft logo & model designators, black
  • Mat package, Kryptek

Standard Features

Hull Color

  • Wellcraft White

Hull and Deck

  • Anchor locker w/ lid, latch & tie off
  • Bow & stern eyes, stainless steel
  • Bow floor storage
  • Cleats, fixed, stainless steel
  • Fiberglass stringer system
  • Foam Flotation
  • Exterior color scheme, all white
  • Horn
  • Ladder, stern, telescoping & folding
  • Meets applicable uscg & canadian regs; nmma certified using abyc stds.
  • Navigation lights, LED
  • Rod holders, deck-mount
  • Rub rail w/ stainless steel insert
  • Thru-hull fittings, stainless steel
  • Fiberglass liner, skid-resistant, self-draining
  • Winning edge owner protection plan

Cockpit

  • Assist handles, stainless steel
  • Baitwell/live well
  • Beverage holder(s)
  • Courtesy light(s)
  • Deck lids, easy-clean underside w/ flush-mount hinges
  • Diamond pattern non-skid
  • Leaning post
  • Helm seating, leaning post w/folding backrest
  • Rod storage, gunnel
  • Seating, forward console
  • Seating, aft folding bench(es)
  • Self bailing cockpit
  • Storage, bow

Helm

  • 12 volt receptacle
  • Steering wheel, stainless steel
  • Cell phone holder
  • USB charge port

Engine / Systems / Drive

  • Battery tray(s), dual w/ switch
  • Bilge pump, automatic

Console

  • Changing room
  • Windscreen, console
  • Head floor, fiberglass liner

Trailer

  • Wellcraft custom trailer, tandem axle w/brakes Galv/Gatorhyde

Power Options

  • Mercury® 115 ELPT 4S

Current Promotion

  • Fall Into Savings (Valid Sept. 6, 2019 to Nov. 30, 2019)

Options

Hull and Deck

  • Anchor w/ rope & chain
  • Rod holders, T-top, clamp-on, stainless steel (2)
  • Underwater lights, LED

Tow Sports

  • Ski tow pylon, removable

Cockpit

  • Cooler, under leaning post (removable)
  • Transom cutting board w/ tool holders
  • Flooring, reed mat, dune (tan), removable
  • Flooring, reed mat, ash (grey), removable

Helm

  • Compass
  • GPS plotter w/depth sounder, Garmin® 741xs

Entertainment

  • Stereo System

Engine / Systems / Drive

  • Battery charger
  • Battery charger w/trolling motor pre-wire
  • Battery on / off switch
  • Down rigger, pre-wire
  • Hydraulic tilt steering (90 & 115 hp only)
  • Raw water wash down
  • Trolling motor pre-wire
  • Trim tabs w/ LED indicators
  • Mercury, Vesselview Mobile

Console

  • Head, porta pottie (NA Canada)
  • Head, pump-out

T-Tops

  • T-top, white frame w/canvas enclosure

Canvas

  • Bimini Top (NA w/T-Top)
  • Console cover
  • Sail Shade

Trailer

  • Spare tire & wheel, galvanized or aluminum
  • Wheels, aluminum
  • Trailer delete
  • EZ-loader, tandem axle, aluminum w/brakes & spare

Power Options

  • Yamaha® F115 XB
  • Yamaha® F150 XB
  • Yamaha® F200XB
  • Mercury® 150 XL 4S
  • Mercury® 200 FS DTS
  • Mercury® 200 FS DTS Warm White
For a complete list of features, options and available power, see an authorized Wellcraft dealer for additional details. wellcraft.com
