The 302 Fisherman, specializing in offshore boating, provides all the provisions anglers need to hook, land, and stow large gamefish. This vessel is spacious and multifunctional­ to ensure you're ready for stress-free fishing and cruising.

Specifications

L.O.A 30' 2" 9.2 m
Beam 9' 8" 2.9 m
Fuel Capacity 268 gal 1014 L
Approx. Draft Up 23" 58 cm
Approx. Draft Down 31" 79 cm
Maximum Capacity Yacht 4100 lbs
Persons Capacity Yacht 1
Approx. Boat & Engine Weight 9200 lbs 4173 kg
Max HP 800 597 kW
Deadrise 22° 22°
Bridge Clearance w/T-Top 8' 2" 2.5 m
Water Capacity 13 gal 49 L
Total height on Trailer w/Top 11' 11" 3.6 m
Persons Capacity CE 12 12

Standard Features

Hull Color

  • Wellcraft White Top

Entertainment

  • Stereo system, 4 Speakers
  • Stereo system w/ deluxe T-Top, 4 speakers (req. deluxe T-top)
  • USB ports

Hull and Deck

  • Rod holders, deck-mount
  • Bow rails, recessed
  • Anchor roller, bow
  • Rod holders, stern, transom mount
  • Under hardtop color scheme, all white
  • Meets applicable uscg & canadian regs; nmma certified using abyc stds.
  • Underwater fittings, bronze
  • Cleats, pull-up, stainless steel
  • Ladder, stern, retractable
  • Anchor locker w/ lid, latch & tie off
  • Winning edge owner protection plan
  • Horn
  • Exterior color scheme, all white
  • Navigation lights, LED
  • Powdercoat, choice of color (leaning post and optional T-top frame)
  • Rub rail w/ stainless steel insert
  • Bow anchor roller
  • Thru-hull fittings, stainless steel
  • Transom lighting, LED
  • Bow & stern eyes, stainless steel
  • Fiberglass stringer system
  • Powdercoat, white (leaning post and optional T-top frame)

Console / Cabin

  • Lighting
  • Changing room, w/ sink, faucet & electric toilet
  • Port light window, opening
  • Storage, curtains
  • Counter top, corian
  • Mirror
  • Head, electric, porcelain toilet w/ holding tank
  • Windshield, deluxe w/side entry door
  • Flooring, fiberglass liner
  • Outlets, 110v (Inc. w/ dockside power)

Helm

  • Compass
  • Steering wheel, stainless steel
  • Custom gauges. system matched
  • Cell phone holder

Engine / Systems / Drive

  • Battery on/off switch
  • Outlet, 12V
  • Power assisted steering, Yamaha engines
  • Bilge pump, automatic
  • Raw Water Wash Down
  • Mercury power steering (req. 200 hp Mercury engines)
  • Active trim (Mercury only)
  • Battery tray(s)
  • Outlet, USB charge port(s)
  • Hydraulic tilt steering (std on 150 hp and up)
  • Trim tabs w/ LED indicators

Cockpit

  • Courtesy light(s)
  • Transom door
  • Cooler, helm seat, carry-on w/ slider & drain-able storage
  • Bucket in holder, bow, 5 gal
  • Self bailing cockpit
  • Tackle storage w/ boxes
  • Storage, bow
  • Beverage holder(s), stainless steel
  • Upholstery, premium vinyl w/ drain/dry-fast marine-grade foam
  • Seating, forward lounge
  • Fiberglass liner, skid-resistant, self-draining
  • Deck lids, easy-clean underside w/ flush-mount hinges
  • Assist handles, powdercoat
  • Interior color scheme, choice of color
  • Cutting station, aft
  • Water intrusion management systems
  • Seating, aft folding bench(es)
  • Cockpit sink w/transom shower & fresh water system
  • Rod storage, gunnel
  • Helm seating, dual captain chair w/ armrests
  • Baitwell, stern w/ bluecoat, light & timer, 23 gal (2)
  • Non-skid, mechanical pattern
  • Coaming bolsters w/ rich hand-fitted vinyl & comfort padding
  • Storage/fishbox(es), floor w/ macerator and overboard drain

Power Options

  • Twin Yamaha® F300 XSB

T-Tops

  • T-top, deluxe w/ ladder back, LED lights, electronics box, spreader lights, rod holders & phone holder

Options

Power Options

  • Twin Mercury® 350 XL Verado JPO White
  • Twin Yamaha® F300 XSB with Helm Master
  • Twin Mercury® 300 XL Verado
  • Twin Mercury® 350 XL Verado White
  • Twin Mercury® 300 XL Verado JPO White
  • Twin Mercury® 400 XL Verado White
  • Twin Mercury® 300 XL Verado White
  • Twin Mercury® 350 XL Verado
  • Twin Yamaha® F300 XSB2 White
  • Twin Mercury® 400 XL Verado JPO
  • Twin Mercury® 300 XL Verado JPO
  • Twin Mercury® 400 XL Verado
  • Twin Mercury® 350 XL Verado JPO
  • Twin Yamaha® F300 XSB2 with Helm Master White
  • Twin Mercury® 400 XL Verado JPO White

Helm

  • Night vision, FLIR® (req. GPS)
  • Radar 4KW-Open Array, Garmin (req. GPS)
  • GPS plotter w/depth sounder, Garmin®8616XSV MFD w/ 1KW transducer
  • Transducer, 1kw
  • VHF radio, Garmin® 110

Console / Cabin

  • Flooring, wood
  • Head, overboard discharge *requires electric head

Cockpit

  • Storage trays, aft, port, starboard, tilt out
  • Flooring, reed mat, ash (grey), removable
  • Flooring, reed mat, dune (tan), removable
  • Seating, aft folding bench(es) delete
  • Marine Mat, helm footrest & rod storage, diamond pattern
  • Refrigerator, cockpit
  • Table, bow
  • Cooler, bow
  • Bow fill-in cushion (req. bow seating pkg., bow cooler & bow table)
  • Storage trays w/ dive door, aft, tilt out
  • Seating, backrest, forward facing, removable
  • Seating, forward lounge, convertible
  • Grill, cockpit (requires dockside power)

Canvas

  • Sail shade w/ carbon fiber poles
  • Spray shields, Eisenglass (t-top only)
  • Console & helm seat cover

Hull and Deck

  • Powdercoat, black (leaning post and optional T-top frame)
  • Underwater lights, LED
  • Under hardtop color scheme, choice of color (req. deluxe T-top)
  • Anchor w/ rope & chain
  • Ladder, dive door
  • Dive door
  • Windlass w/bow roller, rope, chain & anchor

Engine / Systems / Drive

  • Battery charger, Pro-Sport 20 amp 3 bank
  • Dockside power (includes battery charger)

Packages

Bow seating package

  • Backrest cushions, bow
  • Seat cushions, bow

Premium sound package w/ deluxe T-top

  • Amplifier(s), JL Audio®
  • Stereo, Fusion®
  • Speakers, JL Audio® (6)
  • Subwoofer(s), JL Audio®

Scarab Offshore Package

  • Marine Mat, helm footrest & rod storage, diamond pattern
  • Scarab Offshore Graphic (silver)
This information is for reference only, and the actual design, specifications, and options may vary from the photos and other information shown. Contact your dealer for more information.
For a complete list of features, options and available power, see an authorized Wellcraft dealer for additional details. wellcraft.com
