The 302 Fisherman, specializing in offshore boating, provides all the provisions anglers need to hook, land, and stow large gamefish. This vessel is spacious and multifunctional­ to ensure you're ready for stress-free fishing and cruising.

Color Options

Specifications

L.O.A 30' 2" 9.2 m
Beam 9' 8" 2.9 m
Fuel Capacity 268 gal 1014 L
Approx. Draft Up 23" 58 cm
Approx. Draft Down 31" 79 cm
Approx. Boat & Engine Weight 9200 lbs 4173 kg
Max HP 800 HP 597 kW
Deadrise 22° 22°
Bridge Clearance w/T-Top 8' 2" 2.5 m
Water Capacity 13 gal 49 L
Total height on Trailer w/Top 11' 11" 3.6 m

Standard Features

Hull and Deck

  • Anchor locker w/ lid, latch & tie off
  • Bow & stern eyes, stainless steel
  • Cleats, pull-up, stainless steel
  • Fiberglass stringer system
  • Exterior color scheme, all white
  • Horn
  • Meets applicable uscg & canadian regs; nmma certified using abyc stds.
  • Navigation lights, LED
  • Rod holders, deck-mount
  • Rub rail w/ stainless steel insert
  • Thru-hull fittings, stainless steel
  • Bow anchor roller
  • Bow rails, recessed
  • Under hardtop color scheme, all white
  • Ladder, stern, retractable
  • Powdercoat, white
  • Winning edge owner protection plan
  • Transom lighting, LED
  • Powdercoat, choice of color
  • Rod holders, stern, transom mount
  • Underwater fittings, bronze

Cockpit

  • Assist handles, powdercoat
  • Coaming bolsters w/ rich hand-fitted vinyl & comfort padding
  • Courtesy light(s)
  • Transom cutting board w/ tool holders
  • Rod storage, gunnel
  • Self bailing cockpit
  • Tackle storage w/ boxes
  • Bucket in holder, bow, 5 gal
  • Deck lids, easy-clean underside w/ flush-mount hinges
  • Seating, aft folding bench(es)
  • Helm seating, dual captain chair w/ armrests
  • Cockpit sink w/transom shower & fresh water system
  • Beverage holder(s), stainless steel
  • Cutting station, aft
  • Storage, bow
  • Fiberglass liner, skid-resistant, self-draining
  • Baitwell, stern w/ bluecoat, light & timer, 23 gal (2)
  • Cooler, helm seat, carry-on w/ slider & drain-able storage
  • Interior color scheme, choice of color
  • Non-skid, mechanical pattern
  • Storage/fishbox(es), floor w/ macerator and overboard drain
  • Upholstery, premium vinyl w/ drain/dry-fast marine-grade foam
  • Water intrusion management systems
  • Transom door
  • Seating, forward lounge

Helm

  • Compass
  • Steering wheel, stainless steel
  • Cell phone holder
  • Custom gauges. system matched

Entertainment

  • Stereo system, 4 Speakers
  • Stereo system w/ deluxe T-Top, 4 speakers (req. deluxe T-top)
  • Speakers (4)
  • USB ports

Engine / Systems / Drive

  • Bilge pump, automatic
  • Hydraulic tilt steering (std on 150 hp and up)
  • Raw water wash down
  • Trim tabs w/ LED indicators
  • Battery (ies), on / off switch (es)
  • Active trim (Mercury only)
  • Battery tray(s)
  • Outlet, 12V
  • Outlet, USB charge port(s)
  • Mercury power steering (req. 200 hp Mercury engines)

Power Options

  • Twin Yamaha® F250 XCB

Under Hardtop Color

  • Wellcraft White

Console / Cabin

  • Changing room, w/ sink, faucet & electric toilet
  • Counter top, corian
  • Flooring, fiberglass liner
  • Head, electric, porcelain toilet w/ holding tank
  • Lighting
  • Mirror
  • Outlets, 110v (Inc. w/ dockside power)
  • Port light window, opening
  • Storage, curtains
  • Windshield, deluxe w/side entry door

T-Tops

  • T-top, deluxe w/ ladder back, LED lights, electronics box, spreader lights, rod holders & phone holder

Hull Color

  • Wellcraft White Top

Options

Hull and Deck

  • Underwater lights, LED
  • Windlass w/rope, chain & anchor
  • Anchor w/ rope & chain
  • Dive door
  • Ladder, dive door
  • Powdercoat, black
  • Under hardtop color scheme, choice of color (req. deluxe T-top)

Cockpit

  • Table, bow
  • Cooler, bow
  • Marine Mat, helm footrest & rod storage, diamond pattern
  • Bow fill-in cushion (req. bow seating pkg., bow cooler & bow table)
  • Grill, cockpit (requires dockside power)
  • Storage trays w/ dive door, aft, tilt out
  • Storage trays, aft, port, starboard, tilt out
  • Flooring, reed mat, dune (tan), removable
  • Seating, backrest, forward facing, removable
  • Seating, forward lounge, convertible
  • Flooring, reed mat, ash (grey), removable
  • Refrigerator, cockpit

Engine / Systems / Drive

  • Battery charger(s)
  • Power assisted steering, Yamaha engines
  • Dockside power (includes battery charger)
  • Down rigger, pre-wire
  • Mercury, Vesselview Mobile
  • Down rigger pre-wire, dual 30A

T-Tops

  • Outriggers, Taco® Grand Slam

Power Options

  • Twin Mercury® 250 XL Verado
  • Twin Mercury® 300 XL Verado
  • Twin Yamaha® F250 XSB with Helm Master
  • Twin Yamaha® F300 XCB with Helm Master
  • Twin Yamaha® F300 XCB
  • Twin Mercury® 350 XL Verado White
  • Twin Mercury® 350 XL Verado
  • Twin Mercury® 350 XL Verado JPO
  • Twin Mercury® 350 XL Verado JPO White
  • Twin Mercury® 250 XL Verado White
  • Twin Mercury® 300 XL Verado JPO
  • Twin Mercury® 300 XL Verado JPO White
  • Twin Yamaha® F300 XCB2 White
  • Twin Yamaha® F300 XCB2 with Helm Master White
  • Twin Mercury® 300 XL Verado White
  • Twin Mercury® 400 XL Verado
  • Twin Mercury® 400 XL Verado White
  • Twin Mercury® 400 XL Verado JPO
  • Twin Mercury® 400 XL Verado JPO White

Canvas

  • Console & helm seat cover
  • Sail shade w/ carbon fiber poles
  • Spray shields, Eisenglass (t-top only)

Helm

  • Radar, Garmin® 624 xHD2, 48" , Open Array (req. GPS)
  • Transducer, 1kw
  • Night vision, FLIR® (req. GPS)
  • GPS plotter w/depth sounder, Garmin®8610xsv mfd w/ 1kw transducer
  • VHF radio, Garmin® 110

Console / Cabin

  • Flooring, wood
  • Head, overboard discharge

Packages

Bow seating package

  • Backrest cushions, bow
  • Seat cushions, bow

Premium sound package w/ deluxe T-top

  • Amplifier(s), JL Audio®
  • Stereo, Fusion®
  • Speakers, JL Audio® (6)
  • Subwoofer(s), JL Audio®

Scarab Offshore Package

  • Marine Mat, helm footrest & rod storage, diamond pattern
  • Scarab Offshore Graphic (silver)
This information is for reference only, and the actual design, specifications, and options may vary from the photos and other information shown. Contact your dealer for more information.
For a complete list of features, options and available power, see an authorized Wellcraft dealer for additional details. wellcraft.com
